Atlas Copco HB4700 Through Bolt for Hydraulic Breaker

HUILIAN replacement through bolt for Atlas Copco HB4700

HUILIAN replacement through bolt for Atlas Copco HB4700 hydraulic breaker enquiries. The through bolt clamps the breaker main body sections. Match its thread, shoulder, length and end interfaces to the old bolt and body configuration. Nuts, inserts, washers and quantities are confirmed separately in the quotation. Send the old part number, model plate, photos and dimensions for a quotation.

Brand Name
Huilian
Part Name
Through Bolt / tensioning bolt / tie rod / breaker long bolt
Suitable for Breaker Brand
Atlas Copco
Breaker Model
HB4700 — confirm serial number and configuration
Related Parts
tensioning nuts, threaded inserts, washers and breaker body components
Position
Main body tensioning and clamping arrangement
Get a free quote
Details
Shipping Policy
Technical Service
After-Sales Guarantee

Atlas Copco HB4700 Through Bolt

HUILIAN supplies replacement through bolt parts for Atlas Copco HB4700 hydraulic breaker enquiries. The through bolt clamps the breaker main body sections. Match its thread, shoulder, length and end interfaces to the old bolt and body configuration. Nuts, inserts, washers and quantities are confirmed separately in the quotation.

Product Specifications and Identification

Specification Details
Supplier brand HUILIAN replacement part
Intended breaker model Atlas Copco HB4700
Part name Through Bolt / tensioning bolt / tie rod / breaker long bolt
Assembly position Main body tensioning and clamping arrangement
Part identification Provide the old part number, breaker serial number and dimensions to identify the required replacement specification.
Measurements to provide overall length, thread diameter and pitch, threaded length, shank and shoulder diameters, end or nut dimensions
Ordering details Send quantity and destination. Price, availability, lead time, packing and supplied components are confirmed in the quotation.

Product Photos

Atlas Copco HB4700 through bolt HUILIAN replacement part view 1

Atlas Copco HB4700 through bolt HUILIAN replacement part view 2

Atlas Copco HB4700 through bolt HUILIAN replacement part view 3

Atlas Copco HB4700 Spare Parts and Part Numbers

Match each reference to the stated model, serial number and assembly version. Kit references identify complete packages; confirm individual component numbers and the replacement packing list separately.

Component or Package Part Reference Version and Ordering Check
Seal kit 3363 1230 02 Standard / DP; confirm serial number
Accumulator repair kit 3363 0898 50 Complete kit reference; not the individual diaphragm number
Tensioning bolt kit 3363 1038 59 Complete kit reference; individual bolt, nut and insert specifications require confirmation

Fitment and Ordering Checklist

  1. Send the Atlas Copco HB4700 model plate, serial number, old-part photos and installed-position photos.
  2. Measure overall length, thread diameter and pitch, threaded length, shank and shoulder diameters, end or nut dimensions.
  3. Send the complete old bolt and both ends, with the model plate and required quantity. A complete tensioning bolt kit reference is distinct from an individual bolt number.
  4. Specify quantity and destination. Confirm the selected components, dimensions and packing list in the quotation.

Related Atlas Copco HB4700 Spare Parts

For a maintenance order, enquire about tensioning nuts, threaded inserts, washers and breaker body components. Each component is supplied separately unless the quotation specifies a set.

Other Hydraulic Breaker Hammer Spare Parts of Our Factory

Our factory can manufacture the hydraulic breaker spare parts listed below. Send your breaker model, part number or drawing, required quantity and material requirements so we can confirm the manufacturing specification and quotation.

Part Type Part Type Part Type Part Type
Back Head Front Head Breaker Cylinder Through Bolt/Tie Rod
Seal Kit Diaphragm/Membrane Rod Pin Stop Pin
Upper Bushing/Inner Bush/Chisel Bush Accumulator Sleeve Valve Piston Ring
Chisel/Tool Thrust Ring Moil Chisel Piston
V-Wedge Chisel Universal Chisel Flat Chisel Damper/Shock Absorber
H-Wedge Chisel Lower Bushing/Outer Bush/Front Cover Rubber Pad Side Bolt
Charging Valve N2 Gas Charging Kit Gas Bottle Lock Pin

HUILIAN factory hydraulic breaker spare parts range

Frequently Asked Questions

How do I order an Atlas Copco HB4700 through bolt?

Provide the old part number, breaker serial number and dimensions to identify the required replacement specification. Send old-part photos, overall length, thread diameter and pitch, threaded length, shank and shoulder diameters, end or nut dimensions, quantity and destination for a quotation.

Which measurements are needed for the HB4700 through bolt?

Please provide overall length, thread diameter and pitch, threaded length, shank and shoulder diameters, end or nut dimensions. Send the complete old bolt and both ends, with the model plate and required quantity. A complete tensioning bolt kit reference is distinct from an individual bolt number.

Can I include other HB4700 spare parts in the order?

You can enquire about tensioning nuts, threaded inserts, washers and breaker body components. Identify each component and quantity separately. The quotation confirms the parts and packing list supplied.

Who supplies this Atlas Copco HB4700 replacement part?

HUILIAN supplies this replacement part for the stated Atlas Copco model. Confirm the selected specification against the old part and breaker configuration before ordering.

Request a Quote

Send the Atlas Copco HB4700 model plate, old through bolt photos, dimensions, part number where available, quantity and destination. HUILIAN will confirm the replacement specification and quotation.
